Model No: TX-SST HMI
Salt spray chamber FRP (Fibre Reinforced Plastic) is the latest technology corrosion test chamber manufactured with high quality FRP (Fibre Reinforced Plastic) body. The instrument has a rugged body with compliance to ASTM B117 standards. The unique FRP body has resistance to high temperature and can withstand extreme corrosive environment. With the help of the latest technology FRP body the in
Need more information or have a question?
Salt spray chamber FRP (Fibre Reinforced Plastic) is the latest technology corrosion test chamber manufactured with high quality FRP (Fibre Reinforced Plastic) body. The instrument has a rugged body with compliance to ASTM B117 standards. The unique FRP body has resistance to high temperature and can withstand extreme corrosive environment. With the help of the latest technology FRP body the instrument has long running life and is capable for conducting the salt spray test for days. The salt spray chamber consists of an in built special reservoir (with float valve) which helps the user in identifying the fluctuation in water level. Salt spray chamber plays a pivotal role to test the specimen and analyse the quality of material being used by manufacturers. The touch screen model of the salt spray corrosion test chamber further provides the user with accurate reports and data test results. These test results are attained in the form of a graphical report. The HMI touch screen model also enhances the user experience and make the instrument easy to operate. The chamber body is highly insulated so as to protect the sample from unwanted dust particles and air. This ensure 100% compliance to ASTM B117 and ensure accuracy. The instrument is also complaint to IP65 which further enhances the life of the chamber body. Testronix also offers various unique features with its instrument. These are best in class top notch features which enhance the user experience and make the instrument easy to operate.
Inbuilt temperature settings
Air Purge and Auto Tuning Facility
Air Saturator Alarm and Auto-Refill facility for safety
Overshoot Temperature Alarm Warning System
Construction: FRP Material
Latest Technology Atomiser Timer
Chamber Canopy/ Hood Angle as per ASTM B117
Sample viewing window
Salt Spray Test feature to enable parameters according to test sample
Temperature and timer functions inbuilt to set all test parameters accurately
Robust Construction with FRP Body to withstand extreme temperatures and extreme corrosive environment
Inbuilt Temperature exceeds alarm Facility to ensure machine safety
Water low level indicator and in built alarm to guide the user
Less maintenance and easy to operate model
FRP Corrosion resistant body as per ASTM B117
Simple placement of samples
User can control PID settings through Advanced Hysteresis setting
Angle of Canopy maintained in order to restrict flow of droplets directly on the test sample as per ASTM B117 standards
Leak proof Hood and 100% insulation to provide accurate results
Pneumatic Hood (Optional Feature to provide user ease)
Inbuilt Air saturator and Fog Collection unit
Microprocessor-based model with auto-tuning feature
Run time vs temperature graph on screen
Data recording with temperature data reading
USB and pen drive options are available to extra data easily
Option available to set PV and SV value
Knox system integrated for data security
User settings can be locked by admin panel and protected by password
User can control PID settings through Advanced setting
|
Test Chamber Temperature Range |
35°C |
|
Chamber Temperature Least Count |
0.1°C |
|
Chamber Temperature Repeatability |
Uniformity ±2°C |
|
Air Saturator Temperature Range |
Upto 50°C |
|
Air Saturator Temperature Least Count |
0.1°C |
|
Air Saturator Temperature Repeatability |
±1°C |
|
pH value of Salt Solution |
6.5 to 7.2 pH |
|
In built PID temperature controller |
Yes |
|
Timer |
Upto 99999 Hours |
|
Test Air Pressure |
0.7 Kg/ cm²& 1.2 Kg/ cm² |
|
Air Regulator |
0 To 7 Kg/ cm² |
|
Air Purging Facility |
Yes |
|
Fog Collector |
Yes |
|
Fog Collection |
1-2ml per 80 cm² per hour as per standards |
|
Measuring Cylinder (External) |
Available (Capacity:50ml) |
|
Power |
220V, Single phase, 50 Hz, 15 A |
|
Reservoir Tank for Solution |
Yes Included |
Optional accessories:
Air saturator- to saturate the air inside the chamber for compliance of ASTM B117
Fog collection unit
pH meter- to check the pH of salt solution
pneumatic opening of canopy for ease in operation
|
Inside Dimensions: |
L x B x H |
|
250 LTR |
800 x 500 x 500 mm |
|
450 LTR |
1000 x 700 x 750 mm |
