How to Place Specimen Accurately on Bursting Strength Tester?

Paper products like corrugated boxes have many applications in the packaging industry. Thus, to ensure that your product will be delivered with utmost care and without any damage, you need to test the bursting strength of the corrugated boxes. Thus, we at Testronix Testing Instruments have come up with an advanced testing instrument known as the bursting strength tester pneumatic model that comes with an automatically compressed gauge to make the operation even much easier. Here in this blog, we are going to provide you with accurate information about how you can easily place the specimen accurately on the bursting strength tester pneumatic model.

Use of bursting strength tester in the packaging industry

Materials like paper, cardboard, boxes, solid fiberboards, and other related materials will easily get burst or rupture with little pressure or force. Thus, with the help of the bursting strength test, you will be able to improve the quality, durability, and performance of materials before shipping them to the customers.

This amazing lab testing equipment comes with a rubber diaphragm and a digital readout of pressure with a peak hold facility. The hydraulic pressure will be applied through the rubber diaphragm at an increasing rate until it ruptures the material.

The gauge in the pneumatic model will easily get tightened automatically. It has been made in accordance with industry-standard like ASTM D 3786-01, ASTM D 3786 – 80A, ISO 1060 PART-1 1987. This laboratory testing equipment will provide you with many advantages for the packaging industry.

• By testing the bursting strength of the package, you will be able to improve the product quality.
• You can easily determine how much pressure your material can withstand.
• The bursting strength testing can be done quickly with the help of this testing machine.
• You will be able to produce a technically correct product that leads to zero rejections.

These are some of the advantages you will get with the use of a bursting strength tester in the packaging industry. You can also read about the significance of bursting strength tester in the packaging industry.

Features of bursting strength tester pneumatic model

This lab testing equipment has been designed in accordance with industrial standards including ASTM D 3786-01, ASTM D 3786 – 80A, ISO 1060 PART-1 1987. Thus, you can easily read about the features of this lab testing instrument mentioned below.

• Push-Button Operation
• Microprocessor-based display for accurate test results
• Peak Hold facility for keeping the maximum value of test result in memory
• Memory to hold up to 9 test reading
• Highly accurate test results under multidirectional Force
• Digital screen for accurate results
• Strong Gripping clamps
• Grooved structure of Test Specimen Holder to provide a firm grip
• The firm grip of the specimen if the operating wheel is tightened uniformly
• Pneumatic/ Hydraulic clamping
• Available in computerized model with thermal print facility
• Available in 0 – 60 kg/cm² on request
• Pressure transducer model for accurate results

Technical Specifications of Bursting Strength Tester Pneumatic model

• Capacity: 0 – 40 kg/cm²
• Display: Digital LED
• Accuracy: ± 1% within 10% to 90% of the entire range as per IS:1828 with the master gauge
• Least Count/Resolution: 0.1 Kg/cm2Power: 220V, Single phase, 50 Hz
• Test fluid: Glycerin about 98% purified
• Rate of fluid displacement: 95 cc/minute
• Motor: 1/4 HP Single Phase, 1440 rpm
• Material: Mild steel, powder-coated
• Clamping: Pneumatic/ Hydraulic
• Dimensions: 540x 600x 450 mm

These are the features and technical specifications of this lab testing instrument. Now, let us discuss the steps to place the specimen accurately in a bursting strength tester (pneumatic model).

Placement of testing specimen at Bursting Strength Tester (pneumatic model)

If you want to correctly place the testing specimen in this testing equipment, then you need to take the follow the steps mentioned below.

• Take a Test specimen of Minimum Dimensions 100 mm X 100 mm.
• Take the upper clamp upwards with the use of a pneumatic cylinder by turning the rotary switch to the OFF position.
• Place the specimen on the lower clamp so that it completely covers the Lower clamp.
• Now bring the upper clamp down on the test specimen with the help of the pneumatic cylinder by turning the switch to ON position.
• Make sure that the test specimen is firmly held and there are no chances of slippage.

In this way, you can easily place the testing specimen in the bursting strength tester pneumatic model. If you find any difficulty in placing the sample, then you can easily call our experts at +91-9313 140 140 or send us an email at info@testronixinstruments.com. We will surely assist you well, regarding your needs and queries.
